Product Overview
Our Chemical Storage Tanks are precision-engineered for the safe, reliable, and contamination-free storage of textile processing chemicals used across wet processing, dyeing, finishing, and coating applications.
Designed to withstand corrosive environments, temperature fluctuations, and continuous industrial usage, these tanks are manufactured in Stainless Steel (SS 304 / SS 316 / SS 316L) or Mild Steel (MS) with internal epoxy coating, depending on chemical compatibility requirements.
These tanks are widely deployed in desizing, scouring, bleaching, dyeing, washing, finishing, and coating plants where chemical stability and safety are critical.
Applications In Textile Industry
Our tanks are specifically designed to store:
- Caustic Soda (NaOH)
- Soda Ash
- Hydrogen Peroxide
- Acetic Acid
- Formic Acid
- Hydrochloric Acid (Diluted)
- Sulphuric Acid (Diluted)
- Enzymes (Amylase, Cellulase, Catalase)
- Wetting Agents
- Sequestering Agents
- Softeners (Cationic / Silicone Based)
- Reactive, Vat & Disperse Dyes (Liquid Form)
- Pigment Pastes
- Optical Brightening Agents (OBA)
- Resin & Finishing Chemicals
- Starch & PVA Solutions
- Textile Auxiliaries & Surfactants
Ready to start your next project?
Design Configurations
Tank Orientation
- Vertical Mounted
- Horizontal Mounted
Bottom Construction Options
- Flat Bottom
- Conical Bottom
- Dish End Bottom
- Sloped Bottom (for complete drainability)
Top Construction Options
- Open Top with Lid
- Dished Top
- Conical Top
- Flanged & Bolted Top
Technical Specifications
Storage Capacity
50 Liters to 20,000 Liters (Custom sizes available)
Material of Construction
- SS 304
- SS 316 / 316L (Recommended for acidic & peroxide chemicals)
- Mild Steel with Chemical Resistant Coating
- SA 516 Gr. 60 / 70 (for pressure-rated applications)
Thickness
Designed as per:
- Chemical compatibility
- Operating temperature
- Load conditions
- Structural requirements
Finishing
- Matt Finish
- Mirror Finish (Pharma / High Purity)
- Painted (MS Tanks)
- Pickled & Passivated (SS Tanks)
Insulation (Optional)
- Hot Insulation (Mineral Wool / Rockwool)
- Cold Insulation (PUF / Foam)
- Cladded with Aluminum / SS Sheet
Ready to start your next project?
Advanced Options
- Limpet Coil for Heating
- Steam Jacketed Construction
- Electrical Heating Coil
- Agitator with Gearbox & Motor
- Level Indicators (Analog / Digital)
- Load Cell Based Level Monitoring
- Dosing Pump Integration
- Bottom Discharge Valve (Butterfly / Ball / Flush Bottom Valve)
- Manhole with Safety Cover
- Vent with Flame Arrestor (for solvent storage)
- Pressure & Vacuum Relief Valve
- Spray Ball for CIP Cleaning
- Sight Glass with Illumination
Safety & Compliance
- Leak-Proof Welded Construction
- Hydrostatic Tested
- Corrosion-Resistant Internal Surface
- Chemical Compatibility Verified
- Earthing Provision for Static Discharge
- Designed as per Industrial Safety Norms
- Compliant with ISO Manufacturing Standards
- CE-Ready Fabrication (On Request)
Ready to start your next project?
Structural Advantages
- High mechanical strength
- Anti-corrosive and anti-abrasive material
- Long service life
- Low maintenance
- Designed for aggressive textile chemicals
- Complete drainability to prevent chemical residue buildup
Typical Installation Areas
- Continuous Desizing & Washing Range
- Chemical Dosing Systems
- Padder Feeding Lines
- Jigger Dyeing Units
- Bleaching & Mercerizing Plants
- Finishing & Coating Lines
- Effluent Treatment Plants (ETP)
Engineering Value
Our Chemical Storage Tanks are not generic vessels — they are process-engineered textile chemical management systems designed to ensure:
- Chemical purity
- Operator safety
- Process consistency
- Reduced contamination
- Long-term durability
Built for modern textile plants demanding reliability, efficiency, and compliance.
